Entering and Using Programs
130
Canceling a programmed timer operation
If a Program Key has been pressed for a timer operation and you need
to cancel the operation before it is performed, follow the steps below.
Note: This procedure will not work for a document stored for a batch
transmission. To cancel a batch transmission operation, see Canceling a
document stored for batch transmission in Batch Transmission in this
chapter.
1
Press the Program Key.
(Example)
B
02
2
Press the START key.
START
all-FO4700.book Page 130 Tuesday, November 28, 2000 2:07 PM
