Sending a Fax by Normal Dialing
40
Sending a Fax by Normal Dialing
With Normal Dialing, you press the SPEAKER key and then dial by
pressing the numeric keys.
♦ Normal Dialing allows you to listen to the line through the speaker
to make sure the other fax machine is responding. (Note that the
speaker is not a speakerphone; it cannot be used for talking.)
♦ If you have connected an extension telephone to the fax machine,
you can also pick up the extension phone and dial using the exten-
sion phone (do not press the SPEAKER key on the fax machine). If
a person answers, you will be able to speak to them through the
phone before sending a fax.
Note: If you press the SPEAKER key to dial, you will not be able to
speak using an extension phone connected to the fax machine in the event
that a person answers.
1
Load the document(s). (Note: If
desired, you can load the document
after dialing in Step 3, below.)
• SEND READY will appear in the
display.
• Set the resolution and/or contrast if
desired.
RESOLUTION
SPEAKER
2
Press the SPEAKER key or pick up
an extension phone connected to the
fax machine. Listen for the dial tone.
Q
CONTRAST
all-FO4700.book Page 40 Tuesday, November 28, 2000 2:07 PM
