Preparation

Standard DIN45325 plug (IEC169-2)

75-ohm coaxial cable (round cable)

Antenna cable

(Commercially available)

Simple operations for watching a TV programme

Basic connection

Connecting to an antenna

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections

that are used for coaxial cable.

Connecting to the power outlet

Before connecting the AC cords, make sure to connect the system cable first.

Display (rear view)

NOTE

• Always turn off the main power of Display when connecting the AC cords.

• Disconnect the AC cords from the AC outlet, Display and AVC System if the System will not be used for a long period of

time.

AVC System (rear view)

AC outlet

LC-65G5X(E)-a 05.10.17, 7:33 AM13
