Preparation

Setting the Display on the wall

• You can mount the Display on the wall, using the optional AN-65AG1 bracket.

• For details, refer to the instructions supplied with the optional bracket.

CAUTION

• Installing the Display requires special skill that should only be performed by qualified service personnel. Customers

should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting

that results in accident or injury.

558

1572

767

923

(mm)

Base bracket

Wall

Wall mount bracket

• Be sure to attach the stand hole

covers (supplied) after detaching

the stand.

Attach the stand hole covers

(supplied) with four screws (edge

cover screws). (For details, refer to

the AN-65AG1 operation manual.)
