8-3
TROUBLESHOOTING
Contents
PAPER MISFEED ILLUSTRATIONS
If you require more information when reading the instructions in the touch panel, see the paper misfeed illustrations
below. Refer to the illustration below and then go to the appropriate illustration (1 to 14) for your situation.
☞ (1)-(2): page 8-3, (3)-(9): page 8-4, (10)-(11): page 8-5, (12)-(14): page 8-6
(1) Original misfeed
Open the document feeder
cover and remove the misfed
originals.
Pull out the document feeder
tray and remove the misfed
paper.
Open the automatic
document feeder. Rotate the
transfer roller in the direction
of the arrow and remove the
original.
(2) Paper misfeed in the output area
Remove the misfed paper.
(1)(11) (12) (13) (2) (10)
(8)
(14) (9)
(3)
(4)
(5)
(6)
(7)
After removing the misfeed, open and close the
automatic document feeder (or the document feeding
area cover or document feeder tray) to clear the
misfeed display from the touch panel.
