2-27
COPIER
Contents
2
Touch the [OK] key.
After touching the [OK] key, make sure that a paper size
suitable for the ratio is selected.
When the automatic document feeder is used, the vertical and horizontal ratio selection ranges are both 25% to 200%.
To return the ratio to 100%...
To return the ratio setting to 100%, touch the [Copy Ratio] key to display the ratio menu and then touch the [100%] key.
System Settings (Administrator): Add or Change Extra Preset Ratios
Two enlargement preset ratios (101% to 400%) and two reduction preset ratios (25% to 99%) can be added. An added
preset ratio can also be changed.
Copy Ratio
OK
Auto Image XY Zoom
121%
129%
64%
77%
100%
%
Zoom
75
11x17
11x17
8½x11
8½x14 8½x11
8½x14
8½x11
5½x8½
8½x11
8½x14
5½x8½ 8½x11
11x17
11x17
1
2
