7-72
SYSTEM SETTINGS
Contents
Auto Color Calibration
This is used to perform automatic color correction when the color in color printing is off. The machine prints a test patch,
the test patch is scanned, and the color is automatically corrected.
After the [Execute] key is touched and a test patch is printed, a message appears prompting you to begin automatic
calibration. Place the test patch on the document glass as shown below (so that the thin line at the edge of the page is to
the left).
Lay copy paper (about five sheets) that is the same size as the test patch on top of the placed test patch, gently close
the automatic document feeder, and touch the [Execute] key.
• Before executing Auto Color Calibration, check to see if the registration adjustment is correct. If the registration adjustment
is not correct, perform "Registration Adjustment" (page 7-61).
• If the color is still off after performing Auto Color Calibration, repeating Auto Color Calibration once again may improve the
color.
