Preparation before Use
2-24
4 Click T next to the Model field and select this machine from the list.
5 Enter the machine’s IP address or host name in the Scanner Address.
NOTE: When the machine’s IP address is unknown, contact Administrator.
6 Click User Authentication Settings. If user login administration is invalid, go to Step 8.
7 Select the checkbox beside Authentication, enter Login User Name (up to 64 characters) and Password (up to
64 characters) and then click OK.
8 Click OK.
9 The machine is registered to the PC and the machine name and model name are displayed in the Scanner List
field.
NOTE: Click Delete to delete the added machine. Click Edit to change names and other settings.
