Timer Transmission
92
6 Press to select SET.
• Note which Timer number (Timer 1, 2,
3, or 4) appears in the display. This is
the number of the Timer job you are
storing.
7 Enter the time at which you want the fax to be sent.
• Enter two-digits for the hour (“00” to “23”) and two-digits for the minute (“00”
to “59”).
Example: 9:25
8 Enter a number as follows to select the day of the operation (skip this
step if the fax will be sent within the next 24 hours):
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
9 Press .
ENTER
The first available
Timer number appears:
TIMER NUMBER=1
ENTER TIME
ENTER STATION #
