Printing on Envelopes and Cards
111
6. Printing
Printing on Envelopes and Cards
To print on envelopes, cards, and other special sizes of paper, use the bypass
tray on the side of the machine.
The bypass tray can be used to print on the following sizes:
A4
A5
Envelope #10 (105 x 241 mm)
Envelope Monarch (98 x 191 mm)
Envelope DL (110 x 220 mm)
A6 (European postcard) (105 x 148 mm)
Letter (216 x 279 mm)
Legal (216 x 356 mm)
♦ Only one sheet (envelope, card, etc.) can be inserted at a time in the
bypass tray.
♦ Be sure to select the correct envelope or paper size in the Page Setup tab
of the SHARP AM-300/400 Printing Preferences (or “Properties”) before
printing. (Select Properties, Setup, or Printer from the Print dialog box to
open the SHARP AM-300/400 Printing Preferences.)
1 Adjust the document guides on the bypass tray to the width of the sheet
or envelope.
