61
Optoelectronics
PHOTOINTERRUPTERS FOR SPECIFIC APPLICATIONS
OPTO
■ Photointerrupters for Specific Applications
◆Transmissive Type
<Case type, with encoder function>
* High precision read and low affection of angle error from vibration thanks to the multi-segment PD system.
Duty ratio: 50±15%, phase difference: 90±45°
<For amusement use>
◆Reflective Type
<Case type, phototransistor output>
❇ Topr: –25 to +85°C *1 Space between prism and sensor is 8 mm.
Model No.
Absolute maximum ratings Electro-optical characteristics
Vcc
(V)
Topr
(°C)
Operating
voltage
Vcc (V)
TYP.
Output signal Resolution
Response frequency Dissipation
current
(output side)
Icc (mA) MAX.
f (kHz)
MAX.
I
F
(mA)
GP1A057RBKLF 6 –10 to +70 3.3
Digital 2 output
(Phase A/B)
Linear scale slit pitch 0.17 (mm) (150LPI) 60 20 7
GP1A054RDKLF 6 –10 to +70 3.3 Linear scale slit pitch 0.0847 (mm) (300LPI) 60 20 5.5
GP1A057SGKLF 6 –10 to +70 3.3 Linear scale slit pitch 0.56 (mm) (45LPI) 25 20 5.5
GP1A058SCK0F 6 –10 to +70 3.3 Linear scale slit pitch 0.14 (mm) (180LPI) 60 20 5.5
GP1A101C2KSF 6.5 –10 to +70 3.3
Digital 2 output
(Multiplying output)
Resolution for reading: 180 LPI
(Pitch: 0.14 mm)
Output resolution: 360 LPI
120 20 20
GP1A054RDKLF GP1A057RBKLF
(GP1A057SGKLF)
GP1A058SCK0F GP1A101C2KSF
Model No.
Internal
connection
diagram
Features
Detecting
and emitting
gap
(mm)
Slit width
(mm)
Electro-optical characteristics
Operating voltage
Vcc (V)
Low level output voltage
MIN. MAX.
V
OL
(V)
MAX.
Light
cut-off
I
OL
(mA)
V
CC
(V)
GP1A204HCS0
Connector with lock,
screw mounting type,
high resistant to noise
4.0 0.5 10.8 24 0.4 Yes 5 10.8 to 24
GP1A204HCS0
Model No.
Internal
connection
diagram
Features
Electro-optical characteristics
Peak photocurrent Response time
I
CP
(mA)
I
F
(mA)
V
CE
(V)
tr (µs)
TYP.
I
C
(mA)
R
L
(kΩ)
V
CE
(V)
GP2S29SVJ00F
Long focal distance (with prism system*
1
),
compact, screw mounting type
0.4 to
3.0
*1
20 5 38 0.5 1 2
GP2S29SVJ00F
(Ta = 25°C)
(Ta = 0 to +40°C)
Voltage regulator
Amplifier
(Ta = 25°C)
Notice
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in
equipment using any SHARP devices shown in catalogs, data books, etc.
Except where specially indicated, models listed on this page comply with the RoHS Directive*. For details, please contact SHARP.
*RoHS Directive: Prohibits use of lead, cadmium, hexavalent chromium, mercury and specific brominated flame retardants
(PBBs and PBDEs), with certain exceptions.
Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
