TOUCH PANEL SYSTEM
LSI
■ Touch Panel System
●Features
●System Configuration
1. By adopting Sharp’s proprietary method, approximately eight times more sensitivity (comparison by Sharp)
has been achieved compared with the conventional sequential driving method.*
Capable of sensing a φ2 mm pen touch, multi-touch operation and touch operation using a glove.
2. Contributes to a thinner design of a touch panel display.
A thinner design is achievable because the design is insusceptible to the noise effect, which makes space for the sensor sheets and
the display modules unnecessary.
3. Common user interface from small to large screens allows for a reduction in software development cost.
* When comparing an S/N ratio of 3.58 determined through the conventional sequential driving method using pen-touch writing on a 20-inch screen with an S/N ratio of
30.65 determined through Sharp’s proprietary parallel driving method (measured by Sharp).
LR388J7
LR388J6
LR0G962
LR0G956
LR0G963
Touch
panel,
up to 5
inches
Touch
panel,
7 to 10
inches
Touch
panel,
10 to 15.6
inches
Touch panel,
20 to 32 inches
Touch panel,
above 32 inches
HOST
HOST
Dedicated
controller
HOST HOST HOST
Product lines
Multiple people can input on the screen
simultaneously, which makes it more
useful on educational sites.
Multi-touch UI on a large screen
for browsing or layout editing.
Pen touch input
is possible.
Operation with a glove
is possible.
Smart TV
PC monitor
Digital signage
Tablet
Notebook PC
Smartphone
eBook
Interactive whiteboard
Table computer
●Application Examples
Notice
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in
equipment using any SHARP devices shown in catalogs, data books, etc.
Except where specially indicated, models listed on this page comply with the RoHS Directive*. For details, please contact SHARP.
*RoHS Directive: Prohibits use of lead, cadmium, hexavalent chromium, mercury and specific brominated flame retardants
(PBBs and PBDEs), with certain exceptions.
Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
