57
Optoelectronics
PHOTOINTERRUPTERS (TRANSMISSIVE TYPE)
OPTO
◆Darlington Phototransistor Output
<Case type>
❇ Topr: –25 to +85°C
◆OPIC Type
<Compact type>
❇ Topr = –25 to +85°C
Model No.
Internal
connection
diagram
Features
Detecting
and
emitting
gap
(mm)
Slit width
(mm)
Electro-optical characteristics
Current transfer ratio Response time
CTR
(%)
MIN.
I
F
(mA)
V
CE
(V)
tr
(µs)
TY
P.
I
C
(mA)
R
L
(Ω)
V
CE
(V)
GP1L50J0000F High sensitivity, both-side mounting type 3.0 0.5 50 1 2 80 2 100 2
GP1L51J0000F High sensitivity, side mounting type 3.0 0.5 50 1 2 80 2 100 2
GP1L52VJ000F High sensitivity, PWB mounting type 3.0 0.5 50 1 2 80 2 100 2
GP1L53VJ000F High sensitivity, PWB mounting type 5.0 0.5 30 1 2 80 2 100 2
GP1L57J0000F High sensitivity, wide gap, PWB mounting type 10.0 1.8 70 1 2 130 2 100 2
GP1L50J0000F GP1L51J0000F GP1L52VJ000F GP1L53VJ000F GP1L57J0000F
Model No.
Internal
connection
diagram
Features
Detecting
and
emitting
gap
(mm)
Slit width
(mm)
Electro-optical characteristics
Threshold input current Propagation delay time
I
FLH
(mA)
MAX.
I
FHL
(mA)
MAX.
V
CC
(V)
R
L
(kΩ)
t
PLH
(µs)
TYP.
t
PHL
(µs)
TYP.
I
F
(mA)
R
L
(kΩ)
V
CC
(V)
GP1A98HCZ0F Compact, PWB mounting 3.2 0.5 8 –
3.3 to
24
3.9 to
20
2.0 10.0 10
3.9 to
20
3.3 to
24
GP1A98HCPSF Compact, surface mount 3.2 0.5 8 –
3.3 to
24
3.9 to
20
2.0 10.0 10
3.9 to
20
3.3 to
24
GP1A98HCZ0F GP1A98HCPSF
(Ta = 25°C)
“OPIC” (Optical IC) is a trademark of SHARP Corporation. An OPIC consists of a
light-detecting element and signal-processing circuit integrated onto a single chip.
()
(Ta = 25°C)
Amplifier
Voltage
regulator
Notice
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in
equipment using any SHARP devices shown in catalogs, data books, etc.
Except where specially indicated, models listed on this page comply with the RoHS Directive*. For details, please contact SHARP.
*RoHS Directive: Prohibits use of lead, cadmium, hexavalent chromium, mercury and specific brominated flame retardants
(PBBs and PBDEs), with certain exceptions.
Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
