6 Accessories

www.turnerbiosystems.com 44

6.3.3 Changing the Battery

1. Remove the two Phillips head screws.

2. Remove the battery retainer plate.

3. Pull the battery out of the battery compartment.

4. Install the new battery (4LR61) with notch aligned according to the drawing.

5. Reinstall the battery retainer plate.

6. Replace the two Phillips head screws.

7. Press the “Start” button while observing the “Battery Check” indicator to ensure the light

plate is working (green light should appear).

6.4 USB Flash Drive (105-9300)

The USB Flash Drive (105-9300) included with the Modulus™ Microplate allows data to be

transported to an external computer. It includes 256MB of space, and has been tested to ensure

compatibility with the Modulus™ Microplate Reader.

Most USB flash drives are compatible with the Modulus™ Microplate Reader. USB flash drives

greater than 1GB may take longer than others to be recognized. Wait a few seconds for the

instrument to recognize the USB flash drive. If the problem persists, try a different flash drive.

IMPORTANT: Results files can only be transferred from the instrument to a computer via a

USB flash drive. Use the USB port on the front of the instrument.
