Connections
14
Handset
Connect the handset as shown and place it on the handset rest.
♦
The ends of the handset lead are identical, so they will go into either
socket.
Use the handset to make
ordinary phone calls, or
to transmit and receive
documents manually.
Make sure the handset
lead goes into the
socket marked with a
handset symbol on the
side of the machine!
