Clearing Paper Jams

140

Open the operation panel (grasp the

finger hold and pull up), and then pull

the release on the right side of the

machine forward to open the print

compartment cover.

Gently pull the jammed paper out of

the machine, making sure no torn

pieces of paper remain in the print

compartment or rollers.

Clearing jammed printing paper

Pull the paper release plate forward

and remove the paper.
