Clearing Paper Jams
139
11. Trouble-
shooting
Clearing Paper Jams
Clearing a jammed document
If the original document doesn't feed properly during transmission or
copying, or DOCUMENT JAMMED appears in the display, first try
pressing the START/MEMORY key. If it doesn't feed out, remove it
as follows:
Important:
Do not try to remove a document without opening the operation panel.
This may damage the feeder mechanism.
1
Open the operation panel by grasping
the finger hold and pulling up.
3
Close the operation panel, making
sure it clicks into place.
2
Remove the document.
Click!
