6-23
DOCUMENT FILING
Contents
When Scan to HDD is performed without appending file information, the following user name and file name are automatically
assigned to the file.
User Name: User Unknown
File Name: Mode_Month-Day-Year_Hour-Minute-Second
(Example: HDD_04042010_112030AM)
Stored to: Main Folder
When user authentication is used, the user name that was used for login is automatically selected.
