24
REPLACING SUPPLIES AND MAINTENANCE
10
Install the toner collection container.
☞ Replacing the toner collection container (page 15)
11
Close the front cover.
Take care that your fingers are not pinched when closing the cover.
(1)
(2)
mxc401_us_saf.book 24 ページ ２００８年１０月１５日 水曜日 午前１１時５２分
