9300 Mobile Computer
Reference Manual
3.3 SYSTEM SETTINGS
Go to Start | Settings | Control Panel.
Items
Description
In the [Certificates] dialog box, you may view or modify digital certificates that some
application use to establish trust for secure connections.
In the [Date/Time] dialog box, you may change date, time, and time zone settings.
In the [Dialing Properties] dialog box, you may configure settings for modem
communications.
In the [Display Properties] dialog box,
Background tab: Select an image for the background.
Appearance tab: Select a desired color scheme for windows, dialog boxes, and
items.
Backlight tab: Specify for how long the mobile computer is idle and then the
backlight will be automatically turned off while on battery power and external
power respectively. Tap the [Advanced] button to move the slider and adjust the
brightness of the LCD backlight when it is set to be automatically turned on once
a key is pressed or you tap the touch screen.
In the [Input Panel Properties] dialog box,
you may configure how the Soft Input
Panel (SIP) works.
