2-18

SYSTEM SETTINGS

The system settings can be used as needed to meet the needs of your workplace. The items that can be set with the

system settings are shown below.

● Total count . . . . . . . . . . . . . . . . . .The number of pages processed by the machine and optional equipment

can be displayed. (See page 2-20)

● Default settings . . . . . . . . . . . . . . Used to configure the screen contrast, date and time, and keyboard

selection*

settings. (See page 2-20)

● List print . . . . . . . . . . . . . . . . . . . . Used to print lists of settings and fonts. (See page 2-20)

● Paper tray settings . . . . . . . . . . . .The paper type, paper size and automatic tray switching can be set for each

tray. Automatic tray switching allows feeding to switch between trays loaded

with the same type and size of paper. If one tray runs out of paper during

printing, printing will continue from the other tray. (See page 2-20)

For the detailed descriptions and use of the settings listed below, see the fax, image send, and printer

manuals.

● Address control*

. . . . . . . . . . . . . Used to store information for various functions.

● Sender control*

. . . . . . . . . . . . . . Used to store the sender's information that appears on your Scan to E-mail

transmissions at the destination.

● Fax data receive/forward*

. . . . . . Faxes received to memory and received Internet faxes can be forwarded to

another destination.

● Printer condition . . . . . . . . . . . . . . Used to configure default settings for the printer function (see the Operation

manual (for printer)).

●

Document filing control*

. . . . . . . . . Used to configure default settings for the document filing function. (pages 7-25

to 7-28)

● Administrator settings . . . . . . . . . These are items that are used by the administrator of the machine to

configure machine settings. A key appears for these settings in the system

settings menu screen. For information on these settings, see the

administrator settings guide.

These settings can be configured in a system where the facsimile, network scanner and Internet fax function is

available.

These settings can be configured in a system where the network scanner function is available.

General procedure for system settings

Press the [SYSTEM SETTINGS] key.

The system setting

menu screen will

appear.

Touch the key of the desired item to

display its setting screen.

The example of selecting the [DEFAULT SETTINGS]

key and then the [CLOCK] key is explained below.

The system settings are described in detail on the

following pages.

Touch the [CLOCK] key.

Touch the [CLOCK] key and then the following

screen appears.

Touch the year, month, day, hour or minute

key, and then use the or key to

adjust the setting.

●If you select a non-existent date (for example,

Feb. 30), the [OK] key will gray out to prevent

entry of the date.

●Select [DAYLIGHT SAVING TIME SETTING]

checkbox to have the time automatically

change at the beginning and end of daylight

saving time.

JOB STATUS

SYSTEM

SETTINGS

SYSTEM SETTINGS

LIST PRINT

FAX DATA

RECEIVE/FORWARD

PAPER TRAY

SETTINGS

PRINTER

CONDITION

EXIT

DEFAULT

SETTINGS

SENDER CONTROL

ADMINISTRATOR SETTINGS

ADDRESS CONTROL

TOTAL COUNT

DOCUMENT FILING

CONTROL

SYSTEM SETTINGS

CLOCK ADJUST

DATE FORMAT

YEAR MONTH DAY HOUR MINUTE

2010 04 04 11 30

DAYLIGHT SAVING TIME SETTING

dragon_02-2.fm 18 ページ２００６年１１月３０日　木曜日　午後２時１３分
