This document has been published to be used forafter sales service only.The contents are subject to change without notice.Parts marked with “ “ are im

AR-5220 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-1[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES1. Appearance2. Internal1 Document feeder cover (when the

AR-5220 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-34. Motor, solenoid, clutch No.NameCodeFunction operation1 Mirror motor MRM Drives the optical mirror

AR-5220 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-45. Sensor, switchNo. Name Code Function operation1 Mirror home position sensor MHPS Detects the mirr

AR-5220 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-56. PWB unitNo. Name Function operation1 Copy lamp Inverter PWB Copy lamp control2 I / F PWB USB1.1,

AR-5220 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-67. Cross sectional viewNo. Name Function/Operation1 Copy lamp Image radiation lamp2 Copy lamp unit O

AR-5220 UNPACKING AND INSTALLATION 5-1[5]UNPACKING AND INSTALLATION1.Installing conditionsA.Copier installationDo not install your copier in areas tha

AR-5220 UNPACKING AND INSTALLATION 5-2B.Toner cartridge installation1) Shake the toner cartridge several times horizontally, and remove thetape.* Do n

AR-5220 UNPACKING AND INSTALLATION 5-35. Changing the copy paper size in the trayNote•The paper size setting cannot be changed when the machine hassto

Contains lithium-ion battery. Must be disposed of properly.Remove the battery from the product and contactfederal or state environmentalagencies for i

COPYRIGHT 2003 BY SHARP CORPORATIONAll rights reserved.Printed in Japan.No part of this publication may be reproduced,stored in a retrieval system,

 

CONTENTS[1] GENERAL1. Note for servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1[2] SPECIFICATIONS1. Copy mode. . . . . . . . .

AR-5220 GENERAL 1-1[1] GENERAL1. Note for servicingPictogramThe label ( ) in the fusing area of the machine indicates thefollowing: : Caution, risk

AR-5220 SPECIFICATIONS 2-1[2] SPECIFICATIONS1. Copy modeA. TypeB. Machine composition(1) OptionC. Copy speed(1) Scan One Print manyCondition: Copy spe

AR-5220 SPECIFICATIONS 2-2(2) Manual paper feed section(3) Option paper feed unitG. Job speedCondition:With SPF/RSPF A4/Letter Normal 1cassetteH. Mult

AR-5220 SPECIFICATIONS 2-3O. Additional functionsO : Available :Installation of the option is required.X : Not availableP. Other specificationsQ. Pac

3 CONSUMABLE PARTSAR5220 SERIES SRU (LAG)No. ITEM CONTENT LIFE MODEL REMARKS1 Toner Cartridege (Black) with IC TONER X10 19K X 10 AR-01

AR-5220 CONSUMABLE PARTS 3-22. Environmental conditionsA. Transport conditions(1) Transport conditions(2) Storage conditionsB. Use conditionsC. Life(p
