Programming Auto-Dial Numbers
42
4
To program a Rapid Key number,
press a Rapid Key (to select Rapid
Keys 33 through 48, flip up the Rapid
Key overlay).
To program a Speed Dial number,
press the
SPEED DIAL
key and then
enter a number from “1” to “75” on
the FO-4700/FO-5550, or “1” to
“100” on the FO-5700. (If you enter
less than two digits on the FO-4700/
FO-5550, or three digits on the FO-
5700, press the
START
key to
complete the entry.)
Example: Rapid Key 2
or
Speed Dial 1
5
Enter the fax number by pressing the
numeric keys (max. of 34 digits
including pauses).
• To clear a mistake, press the
CLEAR
key.
• If a pause is required between any
of the digits to access a special
service or an outside line, press the
REDIAL
key (two seconds per
pause). The pause will appear as a
hyphen. Several pauses can be
entered in a row.
6
Press the
START
key.
(Example)
1
SPEED DIAL
B
2
3
2
1
4 4
1 1
START
START
all-FO4700.book Page 42 Friday, June 11, 1999 1:57 PM
