7-24
CHAPTER7
OPTIONAL EQUIPMENT
Finisher (AR-FN4)
FINISHER (AR-FN4)
Staple jam removal
If staples become jammed in the stapler, the message “CHECK
STAPLER POSITION OR STAPLE JAM” will appear. Remove the
jammed staples in the manner described below:
1
While holding the finisher release lever, slide the finisher
away from the copier.
2
Pull out the staple box.
●
To prevent bumping or scraping your hand during removal of the
staple box, proceed as shown in the illustration and as follows:
Grasp the staple box with your thumb and index finger, and place
the heel of your hand against the finisher frame as shown with
arrow
1
in the illustration.
Remove the staple box in the direction of arrow
2
by squeezing
with your fingers and rotating against the heel of your hand.
3
Lower the lever at the end of the staple box and remove
the jammed staples.
4
Return the lever to its original position.
