7-11

CHAPTER7

20-BIN STAPLE SORTER (AR-SS2)

Open the stapler cover.

Lift the release lever and pull out the staple box.

●

Lift the release lever to unlock the staple box. Then pull out the

box.

Lower the lever at the end of the staple box and remove

the jammed staples.

Return the lever to its original position.

Staple jam removal

If staples become jammed in the stapler, the message “CHECK

STAPLER POSITION OR STAPLE JAM.” will appear. Remove the

jammed staples in the manner described below:

OPTIONAL EQUIPMENT

20-bin staple sorter (AR-SS2)
