SPECIAL MODES
5-29
5
4
Touch the outer [OK] key.
You will return to the
main screen of copy
mode.
5
Place the original on the document glass.
Place the front side of
the original face down
and close the
document cover.
6
Follow steps 4 through 6 of "Copying from
the document glass" (page 4-12).
7
Press the [START] key.
The front side of the
card is scanned.
8
Place the back side of the original face
down on the document glass (see step 5).
9
Press the [START] key.
The back side of the
card is scanned.
10
Touch the [READ-END] key.
SIZE RESET
CANCEL OK
OK
FIT TO
PAGE
NOTE
The original must be placed on the document glass.
The document feeder (automatic document feeding
function) cannot be used.
To cancel the card shot function, touch the
[CANCEL] key in the card shot setting screen (the
screen of step 4).
