NORMAL COPYING
5-5
5
Copy output (sort and group)
Example: Making five sets or five copies each of three originals
● Sorting copies into sets
● Grouping copies by page
About the offset function
This function offsets each set of copies from the
previous set in the output tray, making it easy to
separate sets of copies.
(Offset can function for output to the center tray or in
the offset tray of the saddle stitch finisher.)
Turning on the offset function
The offset function operates when a checkmark
appears in the [OFFSET] checkbox, which is
displayed by touching the [CENTER TRAY] key. (If a
checkmark doesn't appear, touch the checkbox.)
Offset width: Approximately 1-3/10" (30 mm)
(12" x 18" (A3W) paper cannot be offset.)
SPECIAL MODES
2-SIDED COPY
OUTPUT
OUTPUT
½Ã˚ÌßÙ
¿˚Ä
SORT
GROUP
Original
Press the [BLACK
COPY START] key
Press the [COLOR
COPY START] key
Set the
number of
copies (5)
Touch the
[OUTPUT] key
Touch the
[SORT] key
Five sets of copies
"Sort" is automatically selected when the
original is placed on the document feeder tray
of the reversing automatic document feeder.
SPECIAL MODES
2-SIDED COPY
OUTPUT
OUTPUT
SORT
GROUP
Original
Press the [BLACK
COPY START] key
Press the [COLOR
COPY START] key
Set the
number of
copies (5)
Touch the
[OUTPUT] key
Touch the
[GROUP] key
5 copies per page
"Group" is automatically selected when the
original is placed on the document glass.
Offset function "ON"
Offset function "OFF"
INTERRUPT
READY TO COPY.
0
OK
OUTPUT
SORT
GROUP
OFFSET
CENTER
TRAY
LEFT TRAY
Selecting the output tray
When the [LEFT TRAY] key in the above illustration
is highlighted, copies are output to the tray on the
left side of the machine (the left tray). When the
[CENTER TRAY] key is highlighted, copies are
output to the center tray. Touch the key of the tray
you wish to use for copy output.
WhaleII_general-copy_SEC.book 5 ページ ２００４年９月１４日 火曜日 午前１１時４５分
