3-15
3
LARGE CAPACITY TRAY
The large capacity tray can hold approximately 3,500 sheets (21 lbs. (80 g/m
2
)) of 8-1/2" x 11" (A4) size paper.
(For the types of paper that can be loaded in the large capacity tray, see "Large Capacity tray" in the tray
specifications (page 2-9).)
Part name
Specifications
Specifications are subject to change for improvement without notice.
NOTES
● Do not place heavy objects on the large capacity tray or press down hard on the tray.
● To install the large capacity tray, the optional duplex module/2 x 500 sheet paper drawer or the stand/3 x 500
sheet paper drawer must also be installed.
Name LARGE CAPACITY TRAY (AR-LC8)
Paper size 8-1/2" x 11" (A4)
Paper weight 17 to 28 lbs. (64 to 105 g/m
2
)
Number of trays 1 tray
Paper capacity 3,500 sheets (21 lbs. or 80 g/m
2
)
Power supply Supplied from machine
Dimensions
14-13/16" (W) x 21-15/32" (D) x 23-7/16" (H)
(376 mm (W) x 545 mm (D) x 595 mm (H))
Weight* Approximately 66.2 lbs. (30kg) *without mounting kit
Overall dimensions when
attached to machine
38-7/16" (W) x 26-5/8" (D) (976 mm (W) x 676 mm (D))
Top cover
Open for misfeed removal.
Release lever
