PLASMACLUSTER ION GENERATING UNIT REPLACEMEN

HOW TO REPLACE THE PLASMACLUSTER

ION GENERATING UNIT

*When replacing the Plasmacluster Ion Generating Unit, be sure to turn off the

main unit, unplug the power cord, and never handle the plug with wet hands.

Remove the

LOUVERS.

Remove the TOP

COVER CAP.

Turn the 2 SCREWS

SCREWS

Lift up the TOP

COVER.

Replace the

Plasmacluster Ion

Generating Unit.

Suggest replacing

*See the manual of Plasmacluster Ion

Generating Unit for replacement.
