Audio connections

SPDIF connection

Example of connectable devices

Dolby Digital Surround Sound System E

RF IN

RF OUT

USB

ETHERNET SPDIF HDMI VCR

12VDC-2A

AUDIO INPUT

CD VCR TV

DIGITAL INPUT

COAX 1

OPTICAL

COAX 2

SPEAKER OUTPUT

FR FL C RL RR

POWER

FUSE

T2AL/250V

OFF

AC 230V - 50Hz

After connecting E

Digital audio output setting

After connecting to a surround sound system with a SPDIF cable, you should set an audio output format compatible

with the programme you are watching or the device connected (Page 17).

Connecting external devices
