5-42
SCANNER/INTERNET FAX
Contents
4
To change the file name, touch the [File
Name] key.
The file name is entered in the same way as the subject.
5
To change the body text, touch the
[Body Text] key.
6
Enter the body text and touch the [OK]
key.
• To select a pre-set message previously stored in the Web
page, touch the [Pre-Set Select] key.
• To directly enter the message, touch the [Edit] key.
• 1800 characters can be entered. (A line break counts as one character.)
• To clear all entered text, touch the [Clear All] key. When this key is touched, the entire body of the message is
erased immediately; not just the selected line.
• Each line of the entered text can be selected with the keys. To edit the selected line, touch the [Edit] key.
The text entry screen will appear with the selected text entered.
Send Settings
OK
Subject
File Name
Body Text
Sub: Schedule coordination meeting
Sub: Schedule coordination meeting
Material for planning meeting
Send Settings
OK
Subject
File Name
Body Text
Body
Entry
Thank you for your continuous support. We have attached scanned data,
which you have requested.
Clear All
OK
Edit
Pre-Set Select
