STATUS INDICATORS

MISFEED REMOVAL

The copier will stop when a misfeed occurs. The misfeed ( ) indicator will

blink.

If paper is accidentally torn during removal, be sure to remove all pieces.

Be careful not to damage the photoconductive drum.

Misfeed removal

Misfeed in the bypass tray

Gently pull the misfed paper out.

Lift slightly on the side cover and slide the cover out

until it stops. Close the side cover by pressing the

handle on the cover.

●

The misfeed ( ) indicator will go out.

Misfeed in the copier

Open the bypass tray. Lift slightly on the side cover and

slide the cover out until it stops.

Check the misfeed location. Remove the misfed paper

following the instructions for each location in the

illustration below.

If the misfed paper is seen from this

side, proceed to “C. Misfeed in the

transport area”.

If paper is misfed here, proceed to

“B. Misfeed in the fusing area”.

If paper is misfed here, proceed to

“A. Misfeed in the paper feed area”.
