Timer Operations
151
6. Special
Functions
5
Press to select A.M. or to select P.M.
6
Press or to select the day on which you want the operation to
take place (if you want the operation to take place within the next 24
hours, select “WITHIN A DAY”.)
7
Press and go to the specific procedure for your operation (see the
following pages).
START/
ENTER
Transmission (SEND MODE)
(Continued from
Initial procedure
.)
8
Dial the receiving machine using one of the following methods:
• Press a Rapid Key.
• Press and enter a Speed Dial number (if you enter less than 3
digits, press to complete the entry).
• Enter a full fax number with the numeric keys.
9
Press .
10
Press and/or to adjust the resolution and contrast if
desired, and then press .
11
Load the document and then press .
• The document will be scanned into memory.
SPEED DIAL
START/
ENTER
START/
ENTER
RESOLUTION
CONTRAST
START/
ENTER
START/
ENTER
