23
WEB FUNCTIONS OF THE MACHINE
4
PRINTER DEFAULT SETTINGS
Configure basic printer settings and printer language settings. The printer default settings consist of the following
three screens.
• Default settings
(page 24): Basic settings that are mainly used when the printer driver is not used (for example,
when printing from a DOS application).
• PCL settings
(page 24): PCL symbol set, font, line feed code, and other settings.
• PostScript settings
(page 24)*:Sets whether or not a PostScript error page is printed when a PostScript error
occurs.
* This setting only appears when the PS3 expansion kit is installed.
Configuring the printer condition settings
1
Click [Condition Settings] in the menu
frame.
The "Default Settings"
screen of the [Condition
Settings] appears. If you
wish to select a setting in
the "Default Settings"
screen, go to step 3.
2
Click the desired setting.
3
Make a selection for the setting in the
screen that appears.
For detailed descriptions of the condition settings,
see "
Printer condition settings" (page 24).
4
Click [Submit] to save the entered
information.
When the printer driver is used and the same settings are configured both in the printer driver and in the above
screens, the settings configured in the printer driver override the settings in the above screens. If a setting is
available in the printer driver, use the printer driver to configure the setting.
Note
