Sharp AR-C360P User’s Guide

Troubleshooting > 64

3. Carefully remove any paper on the belt.

4. If paper is jammed in the fuser unit, push the lock lever (3)

in the direction shown to release the unit.

Holding the fuser unit (4) by the handle, lift it out of the

printer and place it on a flat surface.

WARNING!

Be careful not to touch the fuser unit which may be hot

after printing. If the fuser unit is hot, wait until it cools

before attempting to remove any jammed paper.
