Digital Laser Copier/PrinterOperation Manual MODELAL-1340

82Installation2INSTALLATIONFollow the installation procedure below to use the copier properly.COPIER INSTALLATIONImproper installation may damage the

92InstallationBe sure to allow the required space aroundthe machine for servicing and properventilation.A small amount of ozone is produced within the

102InstallationCHECKING PACKED COMPONENTS ANDACCESSORIESOpen the carton and check if the following components and accessories are included.Power cordT

112InstallationREMOVING PROTECTIVE PACKING MATERIALS1Remove pieces of tape , , , , and and protective cover . Then open theoriginal cover and r

122InstallationINSTALLING THE TD CARTRIDGE2Remove the CAUTION tape from the front cover and remove the two protective pinsfrom the fusing unit by pul

132InstallationINSTALLING THE TD CARTRIDGE6Gently insert the TD cartridge until it locks in place.7Close the front cover and then the side cover by p

142InstallationLOADING COPY PAPER2Remove the pressure plate lock. Rotate the pressure plate lock in the direction of thearrow to remove it while press

152InstallationLOADING COPY PAPER6Gently push the paper tray back into the copier.After loading copy paper, to cancel the blinking “P” without restart

162InstallationPOWER ONTurn the power switch on the left side of the copier to the “ON” position. The ready ( ) indicatorwill light up and other indic

173Making copies3MAKING COPIESThis chapter describes basic copying functions and some other copying functions using themanual bypass.PAPERFor best res

FOR YOUR PROTECTION...To aid in reporting this compact copier in case of loss or theft, please record below the modelnumber and serial number located

183Making copiesNORMAL COPYING1Ensure that paper of the desired size is set in the paper tray. See page 13, LOADINGCOPY PAPER. When copying onto 8-1/2

193Making copiesNORMAL COPYING6Set the number of copies using the two copy quantity ( , ) keys.●Press the clear ( ) key to clear an entry if a mistak

203Making copiesEXPOSURE ADJUSTMENT/PHOTO COPYINGCopy density adjustment is not required for most originals in the automatic exposure mode. Toadjust t

213Making copiesREDUCTION/ENLARGEMENT/ZOOMTo select a preset copy ratio: To select a zoom ratio:Preset reduction and enlargement ratiosare: 50%, 64%,

223Making copiesTWO-SIDED COPYINGTwo-sided copying can be made on this copier using the manual bypass.Example: The following two originals will be cop

234Special functionsSPECIAL FUNCTIONSDESCRIPTION OF SPECIAL FUNCTIONSThis chapter describes the special functions of this copier. Use these functions

244Special functionsTONER SAVE MODE2Press and hold down the exposure mode selector key for approximately 5 seconds.The manual ( ) indicator will go ou

254Special functionsUSER PROGRAMS3Press the print ( ) key. The entered program number will be steadily lit and thecurrently selected parameter number

265Supplies and user maintenance5SUPPLIES AND USER MAINTENANCEThis chapter describes how to replace the TD cartridge and the drum cartridge and how to

275Supplies and user maintenanceTD CARTRIDGE REPLACEMENT3Install a new TD cartridge. To install the new cartridge, see page 11, INSTALLINGTHE TD CART

1CONTENTS1 GETTING STARTEDINTRODUCTION 3CAUTIONS 3MAIN FEATURES 4PART NAMES 6OPERATION PANEL 72 INSTALLATIONCOPIER INSTALLATION

285Supplies and user maintenanceDRUM CARTRIDGE REPLACEMENT4Remove the new drum cartridge from the protective bag and remove the protectivecover from t

295Supplies and user maintenanceOriginal table and original coverStains on the glass or cover will also be copied. Wipe the glass and the cover with a

305Supplies and user maintenanceUSER MAINTENANCE4Return the charger cleaner to its original position. Close the side cover by pressingthe round projec

316Copier trouble?6COPIER TROUBLE?This chapter describes misfeed removal and troubleshooting.MISFEED REMOVALWhen the misfeed ( ) indicator blinks or

326Copier trouble?MISFEED REMOVAL2Close the side cover by pressing the round projections near the side cover openbutton. The misfeed ( ) indicator wil

336Copier trouble?MISFEED REMOVAL3Raise the fusing unit release lever and then close the side cover by pressing theround projections near the side cov

346Copier trouble?TROUBLESHOOTINGIf any problem occurs, check the list below before contacting our Technical AssistanceDepartment.See page:1516——18232

356Copier trouble?STATUS INDICATORSWhen the following indicators light up or blink on the operation panel or the following alphanumericcodes appear in

366Copier trouble?AUTOMATIC EXPOSURE ADJUSTMENTThe automatic exposure level can be adjusted to suit your copying needs.1Press the exposure mode select

377Appendix7APPENDIXSPECIFICATIONSType Digital laser copier/printer, desk-top typeCopy system Dry, electrostatic transferOriginals Sheets, bound docum

25SUPPLIES AND USER MAINTENANCE TD CARTRIDGE REPLACEMENT 26DRUM CARTRIDGE REPLACEMENT 27USER MAINTENANCE 28– Cabinet 28– Original tab

387AppendixSUPPLY PART NUMBERS AND STORAGEWhen ordering supplies, please use the correct part numbers as listed below.Be sure to use only genuine SHAR

397AppendixMOVING INSTRUCTIONSWhen moving this copier, follow the procedure below.When moving this copier, be sure to remove the TD cartridge in advan

INDEXAAuto clear . . . . . . . . . . . . . . . . . . . . 23, 24Automatic exposure adjustment . . . . . . 36Auto power shut-off mode . . . . . . . .

PPacked components . . . . . . . . . . . . . . . 10Paper– loading . . . . . . . . . . . . . . . . . . . . . . . . 13– special . . . . . . . . . . .

MEMO

For users in the USAThis device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not

PRINTED IN CHINA2001J KS TINSE0675QSZZSHARP ELECTRONICS CORPORATIONSharp Plaza, Mahwah, New Jersey 07430-2135.www.sharp-usa.comSHARP ELECTRONICS OF

31Getting started1GETTING STARTEDThis chapter provides basic information for using the copier.INTRODUCTIONThis copier has been designed to provide int

41Getting startedCAUTIONS●Place the copier on a firm, level surface.●Do not install the copier in a humid or dusty location.●When the copier is not us

51Getting startedMAIN FEATURESSubstantial copying functions●Zoom copying from 50% to 200% in 1% increments can be performed.●Continuous copying of max

61Getting startedPART NAMESTransfer chargerTD cartridge lock release buttonTD cartridgeDrum cartridgeDrum cartridge handlePaper feed rollerFusing unit

71Getting startedOPERATION PANELExposure mode selector key andindicatorsUse to sequentially select the exposuremodes: AUTO, MANUAL or PHOTO.Selected m
