IBX-530B-270 Embedded System

Page 81

 Load Optimal Defaults

Use the Load Optimal Defaults option to load the optimal default values for each of the

parameters on the Setup menus. F9 key can be used for this operation.

 Load Failsafe Defaults

Use the Load Failsafe Defaults option to load failsafe default values for each of the

parameters on the Setup menus. F8 key can be used for this operation.
