Acquisition Interface

CS 9300 System User Guide (SM748)_Ed 01 3–17

3D Program Pane

The 3D Program pane enables you to choose different radiological exams. See below

the different radiological exams program pane and their features.

Figure 3–15 Teeth Program Pane

Teeth setting options:

Teeth buttons: Select a group of teeth to be included in the exam. Upper and

lower jaw have the same setting here and will then be designated during the

patient positioning.

Program options:

Fast Acquisition button: Minimizes the acquisition time to help avoid patient

movement.

High Quality Acquisition button: Longer acquisition time with more

projections for maximum quality image.
