4-8

Changing Resolution and Number of Colors

When shipped, your computer is set to the default resolution and color. The default

resolution is 800 x 600 at 64k color. To change the resolution and the number of

colors, perform the following:

In the

Display Properties

dialog box, select

Settings

Select the number of the colors in the

Colors

, and select the resolution in

Screen area

. Refer to the table below.

Click

twice.

Resolutions and Colors you can choose

Resolution

Number of Colors

640 x 480

(1)

256

64K

16M

(3)

800 x 600 256

64K

16M

(3)

1024 x 768

(2)

256

64K

16M

(3)

(1)

You cannot use screen expansion if you choose 16M colors

(2)

Only 800x600 dots are displayed on the internal LCD. Move the cursor to show

the remainder of the 1024x768 dots.

(3)

The number of colors in this mode is made using a Dithering algorithm(on the

internal LCD only).

•

You cannot switch to a display resolution and number of colors that are not

available.

•

In the Color Palette, High Color (16 bit) means 65,536 (64K) colors, and

True Color (24 bit or 32 bit) means about 16,770,000 (16M) colors.

•

If you select True Color(24 bit) in the Color Palette,

* The drawing speed of screen is decreased.

* The speed of displaying video or animation is decreased.

* You cannot use multiple monitors.

•

Note that the above resolutions are ones that you can choose when you

connect a monitor with appropriate resolution.

Using Multiple Displays

You can use multiple displays when an external display is connected. See Windows

Help for more information.
