Sharp FO-4970 Instrukcja Użytkownika Strona 78
- Strona / 86
- Spis treści
- BOOKMARKI
Oceniono. / 5. Na podstawie oceny klientów
NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
FO-4970U
[17] Operation Panel PWB Unit
(Unit)
901 DCEKP496AXH03 BC E Operation panel PWB unit
[18] High Voltage PWB Unit
(Unit)
901 0KW4109620201 BR E High voltage PWB unit
[19] Toner Empty PWB Unit
(Unit)
901 0KW4122010202 BD E Toner empty PWB unit
[20] Memory PWB Unit
1 VCEAPS226AF1C AC C Capacitor(16WV 22µF) [C4]
2 VCEAPS226AF1C AC C Capacitor(16WV 22µF) [C9]
3 VCEAPS226AF1C AC C Capacitor(16WV 22µF) [C10]
4 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C100]
5 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C101]
6 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C102]
7 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C105]
8 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C106]
9 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C107]
10 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C110]
11 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C113]
12 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C116]
13 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C118]
14 QCNCW2590SC5J AM N C Connector(50pin) [CNOP]
15 VHDHRW0502A-1 AD B Diode(HRW0502A) [D1]
16 VHDHRW0502A-1 AD B Diode(HRW0502A) [D2]
17 VHIHD74HC244F AE N B IC,OCTAL BUFFERS(HD74HC244) [IC1]
18 VHIHD74HC244F AE N B IC,OCTAL BUFFERS(HD74HC244) [IC2]
19 VHIHD74HC244F AE N B IC,OCTAL BUFFERS(HD74HC244) [IC3]
20 VHILH28F016SU BR B IC,16Mbit FLASH MEMORY(LH28F016SUT) [IC4]
21 VHIHD74HC138F AE N B IC,3-TO-8 LINE DECORDERS(HD74HC138) [IC6]
22 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R100]
23 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ±5%) [R101]
24 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R102]
25 VRS-CY1JB472J AA C Resistor(1/16W 4.7KΩ ±5%) [R103]
26 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R111]
27 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R112]
28 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R113]
29 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R114]
30 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R115]
31 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R116]
32 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R117]
33 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R118]
34 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R119]
35 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R120]
36 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R121]
37 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R122]
38 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R123]
39 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R124]
40 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R125]
41 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R126]
42 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R127]
43 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R128]
44 VRS-CY1JB910J AB N C Resistor(1/16W 91Ω ±5%) [R129]
(Unit)
901 DCEKM473BXH09 BT N E Memory PWB unit
– 27 –
- SERVICE MANUAL 1
- FACSIMILE 1
- CONTENTS 2
- [1] Specifications 3
- 27 28 29 30 31 32 4
- 39383736353433 4
- [3] Transmittable documents 5
- [4] Installation 5
- [5] Quick reference guide 5
- [1] Adjustments 6
- [3] Troubleshooting 7
- [4] Error code table 7
- [1] Mechanical description 8
- [2] Printer description 8
- [1] Block diagram 9
- [2] Wiring diagram 10
- FO-4970U 11
- Modem block 1 3/16 16
- Modem block 2 4/16 17
- Reading block 5/16 18
- Gate array (B) block 8/16 21
- Codec block 9/16 22
- Page memory block 10/16 23
- Selector block 12/16 25
- Other block 13/16 26
- Connector block 1 14/16 27
- Connector block 2 15/16 28
- JBIG block 16/16 29
- [2] LIU PWB circuit 1/1 32
- LIU PWB parts layout 33
- Printer PWB circuit 2/2 35
- Power Supply PWB parts layout 39
- High Voltage PWB parts layout 43
- Toner Empty PWB parts layout 44
- [8] Memory PWB circuit 1/3 45
- Memory PWB circuit 2/3 46
- Memory PWB circuit 3/3 47
- [1] Protocol 49
- [2] Power on sequence 49
- CHAPTER 8. OTHERS 50
- PARTS GUIDE 51
- I n d e x 79
- © 2001 BY SHARP CORPORATION 86
