Volume Adjustment

You can adjust the volume of the speaker and ringer using the up and down

arrow keys.

1 Press

2 Press or until the display shows the desired volume level.

• Press again to turn off the speaker.

Speaker

5 6

2 3

all.bookPage24Thursday,November15,20014:31PM
