Loading Printing Paper

Print contrast setting

Your fax has been set at the factory to print at normal contrast. If desired, you

can change the print contrast setting to LIGHT.

1 Press once and once.

2 Press once and twice.

3 Press once.

4 Select the print contrast:

NORMAL: LIGHT:

5 Press to return to the date and time display.

FUNCTION

STOP

Display:

The display briefly shows

your selection, then:

OPTION SETTING

PRINT CONTRAST

COPY CUT-OFF

1:NORMAL

all.bookPage18Thursday,November15,20014:31PM
