E-8

HT-E300

2009 April 29

HT-E300_A6_EN.fm

ENGLISH

PL (1)

HU (2)

CZ (3)

SK (4)

UA (5)

RO (6)

LT (7)

GR (8)

EN (9)

Preparation for Use

Note:

Make sure all screws are fully tightened. (screws are not

supplied)

 Installing the speaker

4 Screw the wall mount angle to the wall as shown in the

illustration. (Total screw is 8 pieces)

Wall surface

Wall mount angle

Wall surface

Wall mount angle

(screws x 4)

1 Align the wall mount slot at the speaker to the wall

mount angle.

2 Slot the speaker into the wall mount angle.

3 Fix them securely.

Wall surface
