NORMAL COPYING
4-11
4
Copying from the document glass
When copying originals which cannot be fed from the automatic document feeder such as thick originals, open the
document cover and copy the originals from the document glass.
■ 1-sided copies of 1-sided originals
1
Place the original on the document glass.
(pages 4-3 to 4-6)
●Align the corner of the original with the tip of the
arrow mark on the document glass scale.
●Place the original in the appropriate position for its
size as shown above.
2
Ensure that the 1-sided to 1-sided copy
mode is selected.
The one-sided to one-
sided mode is selected
when no icon for a two-
sided mode appears in
the dashed area on the
display. If an icon
appears, perform steps
3 to 5 on page 4-7 and then go to step 3.
3
Ensure that paper of the same size as the
original is automatically selected*.
The selected tray will be
highlighted or the
message "LOAD xxxxxx
PAPER." will appear. If
the message appears,
load paper in a paper
tray with paper of the
required size.
Even if the message above is displayed, copying
can be performed onto the currently selected
paper.
* The following requirements must be satisfied.
Originals of a standard size (11" x 17", 8-1/2" x 14",
8-1/2" x 11", 8-1/2" x 11"R or 5-1/2" x 8-1/2"R (A3,
B4, A4, A4R, B5, B5R or A5)) are set and the auto
paper select function is enabled.
If originals of a size other
than the sizes above are
to be copied, manually
select the desired paper
size by touching the
[PAPER SELECT] key
and then touching the
desired paper size selection key.
The selected key will be highlighted and the paper
selection screen will close. To close the paper
selection screen without making a selection, touch
the [PAPER SELECT] key.
Original Copy
Original scale
mark
Original scale
mark
5½ x 8½
or A5
8½x11 or A4 11x17 or A3
8½x14
or B4
8½x11R or A4R
ORIGINAL
8 x11
1
/
2
8 x11
1
/
2
8 x11
1
/
2
8 x11
1
/
2
11x17
8 x11R
1
/
2
AUTO
AUTO
100%
8 x11
PAPER SELECT
COPY RATIO
EXPOSURE
1
/
2
READY TO SCAN FOR COPY.
8 x11
1
/
2
PLAIN
1. 8 x11
1
/
2
2. 11x17
3. 11x17
4. 8 x11
1
/
2
PLAIN
PLAIN
PLAIN
PLAIN
