SPECIAL MODES
5-6
Pamphlet copy
The pamphlet copy function is used to arrange copies in proper order for eventual center-stapling and folding into a
booklet. Two original pages are copied onto each side of copy paper. Four pages are, therefore, copied onto one sheet.
This function is convenient for arranging copies into an attractive booklet or pamphlet.
[Example] Copying eight originals in the pamphlet copy mode
● When using this function, a duplex module must
be installed.
● Scan the originals from the first page to the last
page. The order of copying will be automatically
adjusted by the machine.
● Either left binding (right to left turning) or right
binding (left to right turning) can be selected.
●
Four originals will be copied onto one sheet.
Blank pages may be automatically produced at
the end depending on the number of the originals.
● If a saddle stitch finisher is installed, copies can
be stapled in two positions along the center of
copies and folded at the center.
1
Touch the [PAMPHLET COPY] key on the
special modes screen.
The PAMPHLET COPY
setting screen will
appear. The pamphlet
copy icon ( , etc.) will
also appear in the upper
left corner of the screen
to indicate that the
function is turned on.
2
Designate the type of originals to be
copied: 1-sided or 2-sided.
Select the [2-SIDED] key
if you wish to scan a two-
sided original using the
automatic document
feeder.
3
Select the binding position (left binding or
right binding).
If you wish to insert a different type of paper for use as
a cover, follow steps 4 through 12 below.
If you do not wish to insert paper for a cover, continue
from step 8 on the next page.
4
Touch the [COVER SETTING] key.
NOTE
To make pamphlet copies of a book or other bound original, use the book copy function (page 5-26). The book copy
function scans the opened original in two-page units. (Two pages are scanned at each scan, reducing the number
of repetitions of the scanning operation by a half.)
Finished copies are
folded in two.
Originals
(one-sided)
1
2
3
4
5
6
7
8
7
8
5
6
3
4
Originals
(two-sided)
1
2
Left binding
Right binding
First page
First page
To display the special modes screen...
See "General procedure for using special
functions" on page 5-2.
SPECIAL MODES
MARGIN SHIFT
PAMPHLET COPY
ERASE
JOB
BUILD
2-SIDED
ORIGINAL
1-SIDED
RIGHT
BINDING
C
SE
LEFT
BINDING
CANCEL OK
RIGHT
BINDING
COVER
SETTING
NG
