This document has been published to be used forafter sales service only.The contents are subject to change without notice.Parts marked with “ “ are im

AR-FX11 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-43. PWB1 FAX control PWB FAX communication control2 FAX FLASH ROM PWB FAX control program3 TEL/LIU PW

AR-FX11 UNPACKING AND INSTALLATION 5-1[5] UNPACKING AND INSTALLATION<Before installation>• For improvement of workability, some description in t

AR-FX11 UNPACKING AND INSTALLATION 5-24) Reattach the rear cover.<1>Insert the claw locks of the rear cover into the copier, and slide it toleft

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1[6] SIMULATIONS, FAX SOFTWARE SWITCH1. Entering the simulation modePerform the following procedure to ente

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-24. Detail of simulationsMain codeSub codeContents Remark22 11 FAX-related counter display.Used to display

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-346 12 Density adjustment in the FAX mode (Collective adjustments)Used to adjust the density in the FAX mod

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-446 13-16 Density adjustment in the FAX mode (Individual adjustments)Used to adjust the density in the FAX

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-546 39 FAX sharpness adjustmentUsed to adjust the resolution and the filer in the FAX mode. Main codeSub co

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-648 8 FAX magnification ratio adjustment (scan)Used to adjust and set the FAX document scan magnification r

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-748 9 FAX magnification ratio adjustment (print)Used to adjust and set the FAX print magnification ratio an

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-850 8 FAX lead edge adjustment (scan)Used to adjust and set the FAX document scan lead edge position and sc

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-950 9 FAX lead edge adjustment (print)Used to adjust and set the FAX print lead edge position and scan and

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1066 2 FAX soft SW initializingUsed to clear the FAX-related soft SW values except for the line signal adju

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1166 4 Signal send modeUsed to send signals to the line and the machine speaker by setting the signal numbe

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1266 7 Image memory content printUsed to print all the image data (confidential receive contents, remote se

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1366 11 300bps signal sendUsed to send the specified signal at the speed of 300bps by setting the signal nu

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1466 13 Dial testUsed to send the dial pulse and the DTMF signal, and perform the dial pulse make time adju

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1566 17 DTMF signal sendUsed to select the signal send level from 0dB and the soft SW set values and specif

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1666 21 FAX information printUsed to print the following FAX information.24 FAST SRAN clearUsed to clear th

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1766 31 TEL/LIU settingThe following bit 0/1 is alternatively switched. At the same time, the target signal

CONTENTS[1] PRODUCT OUTLINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1[2] CONFIGURATION . . . . . . . . . . . . . . . . . . . . . .

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1866 33 Signal detection checkUsed to detect signals and display the result with ON/OFF.34 Communication ti

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-1966 37 Speaker sound volume adjustmentUsed to send the following test sounds to the line and the speaker t

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-2066 38 Time setting/checkUsed to write/read the time (year, month, day, o'clock, minute) into/from th

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-2166 52 Pseudo ringer check • The pseudo ringer sound is delivered both from the machine (speaker).• This o

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-225. FAX software switchA. Software switch setup change quick reference Large item Medium item Content of s

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-23U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: FranceB. DetailsSWNo.Bit No.Item Switch serection

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-24U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France5 4-8 Not used 11111111110000011111000006 1

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-25U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France92Transfer function 00000Disable YES3 Inter

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-26U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France11 5-8 Distinctive ring Enable only in U.S.

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-27U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France16 1-4 Modem speed (V.33 mode or less)11111

AR-FX11 PRODUCT OUTLINE • CONFIGURATION 1-1[1] PRODUCT OUTLINEThis unit provides the FAX function and the PC-FAX function when installed to the follow

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-28U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France19 1-4 Minimum pause time (10PPS) settingBi

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-29U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France22 3,4 CNG send start time000000.5sec000005

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-30U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France27 5-8 DPMUTE OFF time setting after dialBi

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-31U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France31 3-8 Time specification print (minute) 1

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-32U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France34 1,2 Report output (receive)00000Print Di

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-33U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France37 3 Rotation send selection (A4 A4R)1111

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-34U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France39 8 Interface data output11111YES401Rotati

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-35U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France43 2 Resend in case of an error, Super G3 d

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-36U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France47 1,2 Line monitor speaker sound volume110

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-37U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France51 1,2 Busy tone detection frequency000002p

AR-FX11 SPECIFICATIONS 3-1[3] SPECIFICATIONS1. Fax Function Specification(1) Original(2) Compression Method(3) Image Process(4) Specified Destination(

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-38U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France54 1-8 Not used 000000000000111000000011111

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-39U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France59 7,8 Receive cable amplitude equalizer 00

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-40U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France64 4-8 DTMF send level (High area)Binary in

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-41U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France68 5 Duplex tray print specification (tray

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-42U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France70 4,5 DIS receive process selection in rec

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-43U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France73 2,3 RTN send line error rate1111160lines

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-44U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France75 5,6 ANSam send start wait time000002.25s

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-45U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France81 1-8 Not used 000001111100000111111111100

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-46U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France86 4,5 CI extinction max. OFF time0000010se

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-47U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France92 1-8 Not used 000001111100000111111111100

AR-FX11 SPECIFICATIONS 3-2(7) Transmission Method(8) Record Size(9) F-Code Transmission(10)Other FAX Related Function/RemarksFAST system support PSTN

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-48U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France99 1-8 Not used 000000000000000000000000000

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-49U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1061-8 Not used 111110000011111000001111111

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-50U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1115-8 Print lead edge adjustment (Rear edg

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-51U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1171-8 Scanning magnification ratio adjustm

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-52U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1215-8 Scan effective image area (SPF) back

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-53U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1281,2 Ring sound quality Calling sound rin

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-54U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France1341 Summer time Used to set whether the su

AR-FX11 SIMULATIONS, FAX SOFTWARE SWITCH 6-55U.S.A.: U.S.A. CA: Canada U.K: U.Kingdom GR: German FR: France136 2-8 Not used 00000000000000000000000000

AR-FX11 KEY OPERATOR PROGRAM 7-1[7] KEY OPERATOR PROGRAMKEY OPERATOR PROGRAM Set value(Default) RemarkLIST PRINT/SET LIST PRINT KEY OPE. LISTJUNK FAX

AR-FX11 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-1[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES1. Operation panel1 Page pallet These are used in fax mode

AR-FX11 KEY OPERATOR PROGRAM 7-2*1)Only when an extension phone is connected.*2)If you do not wish to have recalling take place, set the number of att

AR-FX11 TROUBLE CODE LIST 8-1[8] TROUBLE CODE LIST1. FAX-related service call error2. Communication report codesMAIN SUB ConditionsF6 00 FAX board com

AR-FX11 ELECTRICAL SECTION 9-1[9] ELECTRICAL SECTION1. FAX Block diagramCOPIERSCANNERI/FIMAGE PROCESSINGMEMORYSRAM 1MbitResolutionconvertionPRINTI/FA

AR-FX11 ELECTRICAL SECTION 9-22. FAX Circuit diagram8 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(CPU) 1/10VOL[A]PCRXDPCTXDAUDCKWE0-CPU_TDOA13A17A14A

AR-FX11 ELECTRICAL SECTION 9-38 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(FLASH) 2/10D28D17D22D24D30D25D19D21D20D31D16D27D23D26D18D29A2A3A18A14A13A

AR-FX11 ELECTRICAL SECTION 9-48 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(SRAM) 3/10C_BTD15D2D13D1D11D9D7D6D5D12D8D0D4D3D10D14A7A11A8A9A4A3A12A5A6A

AR-FX11 ELECTRICAL SECTION 9-58 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(MCU I/F) 4/10GDATA1GDATA14GDATA6GDATA10GDATA5GDATA2GDATA13GDATA7GDATA3GDA

AR-FX11 ELECTRICAL SECTION 9-68 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(GA1) 5/10IC15uPD65948GL-114-NMU-AA15D11D0A5D12D13D2A12A10D10D15D6D14D4A7A

AR-FX11 ELECTRICAL SECTION 9-7FAX MAIN PWB(GA1-CODEC) 6/10ABCD876 5 24 3 187 6 5 24 3 1ABCDCD1A1CD1A0CD1A2CD1A3M1A10M1A2M1A5M1A0M1A4M1A1M1A3M1A9M1A14M

AR-FX11 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-2For U.S.A.For other countryNOTE• When the auto power shut-off function is activated, All lights exce

AR-FX11 ELECTRICAL SECTION 9-88 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(MN195006E) 7/10D6A8A3D9D15A7A10D13D10A4A6D12D8A11D7D11A5D14A9D5D2D3D4A2A1

AR-FX11 ELECTRICAL SECTION 9-98 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(GA2) 8/10IC22uPD65954GL-084-NMU-AG2D5G2D1G2D7G2D4G2D6G2D3M2A7M2A2M2A6M2A0

AR-FX11 ELECTRICAL SECTION 9-10S D RAM _D5S D RAM _D0SDRAM _A1 0SDRAM _A1 2SDRAM _A 2S DRAM _D1 1S DRAM _D1 0S DRAM _D1 5S DRAM _D1 4S D RAM _D6S D RA

AR-FX11 ELECTRICAL SECTION 9-118 76 5 24 3 1ABCD87 6 5 24 3 1ABCDFAX MAIN PWB(TEL / LIU IF) 10/10MUTESP+SP-SPOUT+5V+5V+5VGN DGN D GNDGN DGNDGN DVSELGN

AR-FX11 ELECTRICAL SECTION 9-12(U): For North America(E): For Europe and AustraliaR without specified W is 1/15W. 1/4W or above without specified size

AR-FX11 ELECTRICAL SECTION 9-13MDM_ASPCLKMDM_ATXDAOUTAFERES-MDM_ABITCLKRGDT-MDM_ARXDCID-HS2-HS1-MDMCLKCID2-AGAGDGAGDGAGDG+24V+5V+3.3VDG+5VS+5VSAGAGL33

LEAD-FREE SOLDERThe PWB’s of this model employs lead-free solder. The “LF” marks indicated on the PWB’s and the Service Manual mean “Lead-Free” solder

q PARTS GUIDECONTENTSSHARP CORPORATIONThis document has been published to be used forafter sales service only.The contents are subject to change w

– 1 –DEFINITIONThe definition of each Rank is as follows and also noted in the listRank A : Maintenance parts, and consumable parts which are not incl

– 2 –1 Packing material & Accessories21222321292121212021191817161612712910811PRP024483562726252824

AR-FX11 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-32. FAX mode (base screen)The base screen of fax mode is displayed by pressing the [FAX] key when the

– 3 –2FAX main PWB unitNO. PARTS CODEPRICERANKNEWMARKPARTRANKDESCRIPTION1 PCOVP1468FCZZ AD D FAX battery cover [BT4]2 QCNCM0149QSPZ AT N C Connector(T

– 4 –2FAX main PWB unitNO. PARTS CODEPRICERANKNEWMARKPARTRANKDESCRIPTION34VCKYCZ1CF104Z AB C Capacitor(16WV 0.1µF) [C240,C243,C246,C247,C249]VCKYCZ1CF

– 5 –2FAX main PWB unitNO. PARTS CODEPRICERANKNEWMARKPARTRANKDESCRIPTION78 VRS-CZ1JD183J AA C Resistor(1/16W 18KΩ ±5%) [R348]79 VRS-CZ1JD202J AA C Res

– 6 –3TEL/LIU PWB unitNO. PARTS CODEPRICERANKNEWMARKPARTRANKDESCRIPTION1 QCNCW0069QSZZ AK C Connector(TX24-30R-12ST-H1) [CN1]2 QJAKT0001FCZZ AD C Conn

– 7 – IndexPARTS CODE NO.PRICERANKNEWMARKPARTRANK[C]CPLTP0378QS021- 7 AR N CCPNLH0040QS021- 9 AT N CCPWBF0178QS311- 11 AY N ECPWBN0173QS311- 22 BQ N E

– 8 –PARTS CODE NO.PRICERANKNEWMARKPARTRANKVRSCY1JD78R7F3- 65 AA CVRS-CZ1JD000J2- 70 AA C"3- 67 AA CVRS-CZ1JD101J2- 71 AA CVRS-CZ1JD102J2- 72 AA

– 9 –MEMO

Contains lithium-ion battery. Must be disposed of properly.Remove the battery from the product and contactfederal or state environmentalagencies for i

COPYRIGHT 2004 BY SHARP CORPORATIONAll rights reserved.Printed in Japan.No part of this publication may be reproduced,stored in a retrieval system,
