LOADING PAPER
The paper required indicator ( ) will light up when there is no copy paper in the selected paper feed station, or
when the selected paper tray is not installed or is improperly installed.
PAPER
For best results, use only SHARP recommended paper.
*
1
5-1/2" x 8-1/2" can be used in the upper paper tray but cannot be used in other trays (including trays in optional paper feeding
unit).
*
2
The number of sheets of the paper which can be set changes with the weight of a paper.
Special papers
Follow these guidelines when using special papers.
●
Use SHARP recommended transparency film and label sheets. Using other than SHARP recommended
paper may result in misfeeds or smudges on the output. If other than SHARP recommended media must
be used, feed each sheet one at a time using the bypass tray (do not attempt continuous copying or
printing).
●
There are many varieties of special paper available on the market, and some cannot be used with this
machine. Before using special paper, contact a SHARP service center.
●
Before using other than SHARP recommended paper, make a test copy to see if the paper is suitable.
Paper tray type Paper type Size Weight Capacity
Paper tray
250-sheet paper
feed unit
2x250-sheet paper
feed unit
Standard paper
Recycled paper
5-1/2" x 8-1/2" *
1
(Invoice)
8-1/2" x 11" (Letter)
8-1/2" x 14" (Legal)
11" x 17" (Ledger)
15 lbs. to 24 lbs.
(56 g/m
2
to 90 g/m
2
)
250 sheets
(Load paper lower
than the line on the
tray)
Bypass tray Standard paper
Recycled paper
5-1/2" x 8-1/2" (Invoice)
8-1/2" x 11" (Letter)
8-1/2" x 14" (Legal)
11" x 17" (Ledger)
15 lbs. to 20 lbs.
(56 g/m
2
to 80 g/m
2
)
100 sheets *
2
Thick paper
Max. 54 lbs. (200
g/
m
2
)
Load one sheet of
these papers at a
time to the bypass
tray.
Transparency film
Labels
Envelopes Commercial 9
(3-7/8" x 8-7/8")
Commercial 10
(4-1/8" x 9-1/2")
International DL
(110 mm x 220 mm)
International C5
(162 mm x 229 mm)
5 sheets
