70
MISFEED REMOVAL
When a misfeed occurs, the error indicator blinks, "CLEAR PAPER JAM" appears in
the display, and the machine stops operating. If a misfeed occurs when using the
RSPF, "RETURN X ORIGINAL(S) START TO RESUME" will appear in the display.
("X" indicates the number of pages to be returned.). This indicates the number of the
originals that must be returned to the document feeder tray after a misfeed. Return
the required number of originals. This number will be cleared when copying is
resumed or the [CLEAR] key ( ) is pressed. If an original misfeed occurs in the
RSPF, the machine will stop and the error indicator will blink. To remove a misfeed
from the RSPF, see "D: Misfeed in the RSPF" (p.73).
1
Open the bypass tray, and
then open the side cover.
2
Check the misfeed location. Remove the misfed paper
following the instructions for each location in the illustration
below. If the error indicator blinks, proceed to "A: Misfeed in
the paper feed area" (p.71).
If paper is misfed here, proceed to "A:
Misfeed in the paper feed area". (p.71)
If paper is misfed here, proceed to "B:
Misfeed in the fusing area". (p.71)
If the misfed paper is seen from
this side, proceed to "C: Misfeed
in the transport area". (p.72)
!AR-208S_208D.book 70 ページ 2007年12月3日 月曜日 午後3時33分
