Supplies and user maintenance

Cabinet

Wipe the cabinet with a soft, clean cloth.

Original table and original cover

Stains on the glass or cover will also be copied. Wipe the glass and the cover with a soft, clean

cloth. If necessary, dampen the cloth with a glass cleaner.

Original table Original cover

Transfer charger

If copies start becoming streaky or blotchy, the transfer charger may be dirty. Clean the charger

using the following procedure.

Turn the power switch off.

Ensure that the bypass tray is open and then open the side cover while pressing the

side cover open button.

Take the charger cleaner out by holding the tab.

Set the charger cleaner onto the right end of transfer charger, gently slide the cleaner

to the left end, and then remove it. Repeat this operation two or three times.

Slide the charger cleaner from the right end to the left end along the groove of

the transfer charger. If the cleaner is stopped on the way, smudges on copies

may occur.

USER MAINTENANCE
