KEY OPERATOR'S GUIDE

RESOLUTION IN AUTO/TEXT MODE

This program is used to set the resolution used when

the exposure mode is set to "AUTO" or "TEXT". When

"300dpi" is selected, the first copy time is shorter than

when "600dpi" is selected.

The factory default setting is "300dpi".

Select "RESOLUTION IN AUTO/TEXT MODE" and

press the [OK] key. The following screen will appear.

Press the [ ] or [ ] key to select the

resolution.

Press the [OK] key.

PHOTO MODE DEFAULT

This program is used to select the method of

expressing halftones when "PHOTO" is selected with

the [EXPOSURE] key for a copy job. Select

"PATTERN 1" or "PATTERN 2" for the method of

expressing halftones.

"PATTERN 1" is recommended for printed photos,

providing sharp images and good expression of

outlines.

"PATTERN 2" is recommended for photos on

photographic paper, providing a soft image.

The factory default setting is "PATTERN 1".

Select "PHOTO MODE DEFAULT" and press the [OK]

key. The following screen will appear.

Select "PATTERN 1" or "PATTERN 2" with

the [ ] or [ ] key.

Press the [OK] key.

LIMIT OF COPIES

This program is used to set the limit for the number of

copies that can be set (and that can appear in the

display) for one copy job.

The factory default setting is "999 copies".

Select "LIMIT OF COPIES" and press the [OK] key.

The following screen will appear.

Select "99 copies" or "999 copies" with the

[] or [] key.

Press the [OK] key.

DISABLE AUTO PAPER SELECTION

This program is used to disable automatic paper

selection. When automatic paper selection is disabled,

the most suitable paper is not selected automatically

when an original is placed on the document glass or in

the document feeder tray.

This function is initially disabled (factory default

setting).

To disable auto paper selection, select "DISABLE

AUTO PAPER SELECTION" and press the [OK] key

so that a checkmark appears in the checkbox.

To re-enable auto paper selection, select

"DISABLE AUTO PAPER SELECTION" once again

and press the [OK] key so that the checkmark is

cleared from the checkbox.

DISABLE 2-SIDED COPY

(Only on models that support two-sided

printing)

Use this program when you wish to disable two-sided

copying or when the two-sided function has failed.

When this program is enabled, only one-sided printing

is possible.

The function is initially disabled (factory default

setting).

To disable two-sided copying, select "DISABLE

2-SIDED COPY" and press the [OK] key so that a

checkmark appears in the checkbox.

To re-enable two-sided copying, select "DISABLE

2-SIDED COPY" once again and press the [OK] key

so that the checkmark is cleared from the

checkbox.

RESOLUTION

300dpi

600dpi

PHOTO MODE DEFAULT

PATTERN 1

PATTERN 2

LIMIT OF COPIES

99 copies

999 copies

Pegasus-E_Copy_Ex.book 88 ページ２００４年９月２３日　木曜日　午前１１時４１分
